SQ3 Black and White-Rectangular Adjustable IP20 3 light surface mount trim for X Series COB Modules
SQ3 Black and White-Rectangular Adjustable IP20 3 light surface mount trim for X Series COB Modules
18 in stock
SKU:SQ3 Black and White
IP20, Adjustable Surface mount ring for X3A, X15A, X20A, XRGBW and XCCT COB down light modules.
Choose this trim if
a. when you want a gimbal square trim.
b. reasonable low profile bezel makes it architecturally very attractive.
c. Low glare rating as the light is set back.
d. if you are planning to use 3 lights in the same trim for more light output or architectural needs.
Do not choose this trim if
a. you are planning to use it in high moisture areas like external eves and shower rooms as its IP20 rated.
Cut out |
90 x 250 mm |
Diameter of face |
100 x 270 mm |
Total height of fitting |
45 mm |
Mounting depth with X3A |
95 mm |
Mounting depth with X15A |
104 mm |
Mounting depth with X20A |
121 mm |
Mounting depth with XRGBW |
95 mm |
Mounting depth with XCCT |
80 mm |
Please note that the light module can be removed without pulling the trim out. This is a design feature of this trim.
Click here to download a pdf spec sheet for SQ3 rectangular adjustable IP20 3 light trim.
